Description
- Brand Name: ABOUTROSE
- Origin: CN(Origin)
- Number of Panels: 1
- Flexible Solar Panel: No
- Foldable Solar Panel: No
- Type: Solar Panel
- Nominal Capacity: 360-degree Installation
- Model Number: Solar Panel
- Number of Cells: 32pcs/36pcs
- Max. Power: 150w
- Size: 1175*540*3mm
- is_customized: Yes
- Material: Monocrystalline Silicon
- Certification: CE
20w flexible solar panel
Package list:
1* 20w solar panel
1* DC USB
1* DC alligator clips
1* DC Cigarette lighter
Specification
Materials: Monocrystalline
Power: 20W
Working Current: 1.11 A
Working Voltage: 18V/5V
Size: Approx. 42*33 cm
DC connector:5.5X2.1 mm
Temperature range : -20-+80
Weight :0.49KG
Standard Test Conditions : lrradiance 1000w/m2,Temperature 25,AM=1.5
1#50w flexible solar panel
Material: Monocrystalline
Type: Flexible
Color: black front &whiteback
Max power: 50w(single piece)
Max power voltage:16v
Max power current: 2.84A
Size: 545mm*534*3mm
2# 50w flexible solar panel
Maximum power(Pmax) 50W
Output tolerance ± 3%
Maximum system voltage 700V DC
Open circuit voltage(Voc) 19.2V
Short circuit current(Isc) 3.43A
Maximum power voltage(Vmp) 16V
Maximum power current(Imp) 3.12A
Cell efficiency 19.5%
Operating temperature(NOCT) 45±2
Temperature range -40-+80
Number of cells 32pcs
Weight 1.03kg
Size 1060*277*3 mm
Color White
Standard Test Conditions : lrradiance 1000w/m^2,Temperature 25, AM=1.5
100w flexible solar panel
Cell material: Monocrystalline silicon
Maximum power(Pmax): 100w
Open Circult Voltage(Voc): 19.4v
Short Circult Current(Isc): 6.5A
Maximum Power Voltage(Vmp):16v
Maximum Power Current(Imp): 6.2A
Maximum System Voltage: 700VDC
Junction Box: IP67 Rated
STC:Irradiance 1000w/m? Temperature 25 AM=1.5
Operating temperature: -20-+80
Size: 1050*540*3mm
Max power should be tested in sunning weather 12:00-14:00am,no Shelter and Sun vertical angle
150w white flexible solar panel
Pmax(Power at Maximum under STC) :150W
Vmp(Voltage at Max Power, V): 18V
Voc(Voltage at Open Circuit, V): 21.6V
STC(Standard Testing Condition:Irradiance 1000w/m² Temperature 25 AM=1.5
Size of module: 1175*540*3MM
Temperature Range: -20±60
Tolerance Wattage: ±5%
Junction Box Type: IP67
Length of Cables: 90cm
Module Efficiency: 23%
Output tolerance: ±5%
Weight: 2.2 kg
150w Black Flexible solar panel
150w solar panel with frame
Maximum power(Pmax) 150W
Output tolerance ± 3%
Maximum system voltage 700V DC
Open circuit voltage(Voc) 21.6V
Maximum power voltage(Vmp) 18V
Cell efficiency 21%
Operating temperature(NOCT) 45±2
Temperature range -40-+80
Number of cells 36pcs
Weight 3100g
Size 1160*530*25 mm
Standard Test Conditions : lrradiance 1000w/m2,Temperature 25,AM=1.5
