Solar Controller 60A 12V 24V 36V 48V MPPT Charger Max 150VDC PV Input 3200W Back-Light Bluetooth LCD Solar Regulator RS485 IP32

$279$361

SKU: 1005002780481489 Category:

Description

  • Brand Name: EASUN POWER
  • Origin: CN(Origin)
  • Certification: NONE
  • Model Number: solar controller 60A
  • Is Smart Device: Yes
  • Application: Charger Controller
  • Application: Solar System Controller
  • Application: Solar Working Station
  • Maximum Current: 60A
  • is_customized: Yes
  • Usage A: controlador solar 60A
  • Usage B: solar controller 60A
  • Usage C: MPPT solar charge controller
  • Description 1: regulador solar 60A
  • Description 2: controlador solar MPPT
  • Function 1: solar regulator 60A MPPT
  • Function 2: regulador solar MPPT
  • Function: solar regulator 60A MPPT
  • Feature: solar charge controller 60A
  • Battery System Voltage: 12V 24V 36V 48V
  • Communication Port: RS485
  • IP Protection: IP32
Note to EU customers:

We opened a new European store,NO VAT!!NO TAX!!The price drops by30-300 Euros!Click on the picture to enter the EU Store.

If you have other questions, please contact us.

Solar Controller 60A 12V 24V 36V 48V MPPT Charger Max 150VDC PV Input 3200W Back-Light Bluetooth LCD Solar Regulator RS485 IP32


Features
•By continuously checking solar panel power output changes, the controllers employ multiple
MPPT charge algorithms in combination to boost charging efficiency in different weather and
temperature conditions.
•Built-in buffer, allows max 25% exceeding rated power input.
•Charging modes available for most common deep-cycle battery types in the market, including
AGM (sealed lead acid batteries), GEL, Flooded, and Lithium.
•Allows mobile phone APP operation for monitoring and parameters settings, with connection
of external blue tooth communication module (optional accessory, not in the standard package
list).
•Auto recognition of 12V/24V battery system voltage by M2440N model; auto recognition of
12V/24V/36V/48V battery system voltage by M4860N model. Lithium battery excluded from this
feature:
•Supports recording of system running data including power generated and power utilized for
up to 300 days, compatible with monitoring App through IOS and Android.
•Provides multiple load control mode options for light based, time based and manually adjusted
scenarios. Low no-load loss.
•Industrial grade design with reverse polarity protection for solar panels, battery and load.

Model No.

ICharger-4860-H

Battery System Voltage

12V/24V/36V/48V Auto (FLD/GEL/SLD)

Manual (Li/User)

No-load Loss

12ma (12V), 10ma (24V)

8ma (36V), 6ma (48V)

Max Solar Input Voltage

<150Voc

Rated Solar Charge Current

60A

Max Solar Input Power

900W/12V 1800W/24V

2600W/36V 3200W/48V

Light Control Voltage

5V*n

Light Control Delay Time

10s

Max Load Output Current

20A

Operating Temperature

-35ºC ~ +45ºC

IP Protection

IP32

Net Weight

3.0 kg

Communication Port

RS485

Operating Altitude

≤ 3000 meters

Controller Dimension

270*185*90 mm

PAYMENT/SHIPPING
  • Import duties, taxes and charges are not included in the item price or shipping charges.These charges are Buyer’s responsibility.

  • Please check with your country customs office to determine what these additional costs will be prior to bidding/buying.

    For custom clearance procedure, If you need help, please let us know

  • WARRANTY/QUALITY:

  • CE certified.

    100% QC before shipment.

    Standard 1 year product warranty

    Warranty will cover only items that are deemed to fail under normal usage. Accidental damage due to environmental causes or incorrect usage and installation will not be covered in warranty (but still serviceable

    Contact us directly for warranty issues

    Buyer is responsible for warranty return shipping.

Additional information

Ships From

China, GERMANY, Poland

Color

NO Bluetooth, With Bluetooth

Current

60A

Rated Voltage

12V 24V 36V 48V
