ECO-WORTHY 100W 120W 150W 195W Watt 18V Volt Mono Solar Panel High Efficiency for RV Home Marine

$160$378

SKU: 1005001520173568 Category:

Description

  • Brand Name: ECO-WORTHY
  • Origin: CN(Origin)
  • Foldable Solar Panel: No
  • Number of Panels: 1
  • Certification: CE
  • Flexible Solar Panel: No
  • Type: Solar Panel
  • Nominal Capacity: 100w120w150w195w
  • Size: depends
  • is_customized: Yes
  • Material: Monocrystalline Silicon
100W/120W/150W/195W 18V Solar Panel For Caravan RV Marine Trailer Camper Van Camping Off-grid system

Features:
1. High cell efficiency with quality silicon materials for long term output stability and reliability.
2. Strictly quality control ensure the stability and reliability, totally 23 testing procedure to do quality control
3. High transmittance low iron tempered glass with enhanced stiffness and impact resistance
4. With advanced encapsulatiing material,laminated in totally automatically machine by experienced technician.
5. Excellent performance in harsh weather
6. Outstanding electrical performance under high temperature and low irradiance conditons

Specification:

Rated Power: 100W

Solar Cell: Monocrystalline

Maximum/Peak Voltage(Vmp): 18V

Open Circuit Voltage(Voc): 21.6 V

Short circuit current: 6.11A

Maximum current: 5.55A

Output Tolerance: ±3%

Temperate coefficient of Isc: (010+/-0.01)%/℃

Temperate coefficient of Voc: -(0.38+/-0.01)%/℃

Temperature range:-40℃~ +85℃

Frame: Aluminum alloy frame

Length of extension cable: 90cm(2.95ft)

Size of extension cable: 4mm²(11AWG)/MC4 Connector

Weight: 13.14 lbs(5.96 kg)

Size: 1010×510×35mm(39.8 x 20.1 x1.4 in)

Rated Power: 120W
Rated Power: 120W
Solar Cell: Monocrystalline
Maximum/Peak Voltage(Vmp): 18V
Open Circuit Voltage(Voc): 21.6 V
Short circuit current: 7.72A
Maximum current: 6.67A
Output Tolerance: ±3%
Temperate coefficient of Isc: (010+/-0.01)%/℃
Temperate coefficient of Voc: -(0.38+/-0.01)%/℃
Temperature range:-40℃~ +85℃
Frame: Aluminum alloy frame
Length of extension cable: 90cm (2.95ft)
Size of extension cable: 4mm² (11AWG) /MC4
ConnectorWeight: 16.5 lbs (7.5 kg)
Size: 945*685*35mm (37.2×26.9×1.4 in)


Rated Power: 150W
Solar Cell: Monocrystalline
Maximum/Peak Voltage(Vmp): 16.6V
Open Circuit Voltage(Voc): 20.3V
Short circuit current: 9.61A
Maximum current: 9.04A
Output Tolerance: ±3%
Temperate coefficient of Isc: (010+/-0.01)%/℃
Temperate coefficient of Voc: -(0.38+/-0.01)%/℃
Temperature range:-40℃~ +85℃
Frame: Aluminum alloy frame
Length of extension cable: 90cm(2.95ft)
Size of extension cable: 4mm²(11AWG)/MC4 Connector
Weight: 21.0 lbs(9.54 kg)
Size: 1315*665*35mm(51.8×26.2×1.4 in)

Rated Power: 195W

Solar Cell: Monocrystalline

Maximum/Peak Voltage(Vmp): 19V

Open Circuit Voltage(Voc): 22.8V

Short circuit current: 12.23A

Maximum current: 10.27A

Output Tolerance: ±3%

Temperate coefficient of Isc: (010+/-0.01)%/℃

Temperate coefficient of Voc: -(0.38+/-0.01)%/℃

Temperature range:-40℃~ +85℃

Frame: Aluminum alloy frame

Weight: 28.2 lbs(12.79 kg)

Size: 1480*668*35mm(58.3×26.3×1.4 in)

Warranty
1. 24 months (counts from purchase day) of quality assurance covering manufacturing defect and malfunction (not include the Man-made damages). Any trouble in using, please contact us we will dobest to solve your problem even replace the item without any charges.
2.If items arrived in poor condition: broken, missing ect, please contact us once received, we offer free replacement immediately.
About Shipping
1.Order needs handing time3 days upmost, expected delivery time within 3 to 7 days. Once receiving your order we will definitely deal with it as soon as possible,we appreciate your kindly understanding and patience.
About Return
1. Accept return&refund within 15 days since purchase, please make sure the package intact and sent it back, we cover shipping cost for damaged and defected items, if order cancel out of buyers’ personal reason, shipping cost will be on buyers.

Additional information

Ships From

GERMANY, United Kingdom, United States

Color

100w, 120w, 150w, 195W
