EASUN POWER 5000W Solar Inverter 5Kva 450Vdc PV 6000W 100A MPPT Parallel Inverter 48V 230V Pure Sine Wave 100A Battery Charger

$1,375$1,440

SKU: 32899640591 Category:

Description

  • Brand Name: EASUN POWER
  • Type: DC/AC Inverters
  • Certification: CE
  • Origin: CN(Origin)
  • Size: 120 x 295 x 468mm
  • Model Number: ISolar SM II 5KW PLUS
  • Output Frequency: 50Hz/60Hz auto detect
  • Output Type: Single
  • Output Power: 1 – 200KW
  • Weight: 13KG
  • is_customized: Yes
  • Output Current: 21.73A
  • Function 1: inverter 48v 220v
  • Description 1: inverter charger
  • Description 2: pure sine wave inverter charger
  • Usage A: inverter 5000W
  • Usage B: Solar Inverter 48V
  • Usage C: pure sine wave inverter
  • Feature: Solar Inverter 220V
  • Output Voltage: 220~ 240V AC
  • Input Voltage: 48Vdc
  • Overcharge Protection: 66 VDC
  • Maximum PV Array Power: 6000W
  • PV Array Open Circuit Voltage: 450 VDC
  • Solar Charge Current: 100A
  • AC Charge Current: 100A
  • Communication Interface: USB and RS232

Attention EU buyers:

The EASUN POWER EU store has opened. You don’t need to pay VAT.
ProductMain Features:

· Sinewave high eficiency inverter charger

· Output power factor 1

· Maximum PV input power 6000W

· The load could be powered from Solar power and AC grid

  even the battery is not available

· Built-in advanced DSP-controlled MPPT solar charge

  controller

· Battery independent design

· Battery equalization function to optimize battery

  performance and extend lifecycle

· Parallel operation with up to 9 units

MODEL

ISolar SM II 5K PLUS

RATEDPOWER

5000VA/5000W

INPUT

Voltage

230VAC

SelectableVoltageRange

170-280VAC(ForPersonalComputers)

90-280VAC(ForHomeAppliances)

FrequencyRange

50Hz/60Hz(Autosensing)

OUTPUT

ACVoltageRegulation(Batt.Mode)

230VAC±5%

Overloadcapacity

5s@150%load;10s@110%~150%load;100ms@200%load

Efficiency(Peak)

90%

TransferTime

10ms(ForPersonalComputers)

20ms(ForHomeAppliances)

Waveform

Puresinewave

BATTERY

BatteryVoltage

48VDC

FloatingChargeVoltage

54VDC

OverchargeProtection

66VDC

SOLARCHARGER&ACCHARGER

SolarChargerType

MPPT

MaximumPVArrayPower

6000W

MPPTRange@OperatingVoltage

120~430VDC

MaximumPVArrayOpenCircuitVoltage

450VDC

MaxmumSolarChargeCurrent

100A

MaximumACChargeCurrent

100A

MaximumChargeCurrent

100A

PHYSICAL

Dimension,DxWxH(mm)

120x295x468

NetWeight(kgs)

11

CommunicationInterface

USBandRS232

ENVIRONMENT

Humidity

5%to95%RelativeHumidity(Non-condensing)

OperatingTemperature

-10°Cto50°C

StorageTemperature

-15°Cto60°C

PAYMENT/SHIPPING

  • Import duties, taxes and charges are not included in the item price or shipping charges.These charges are Buyer’s responsibility.

  • Please check with your country customs office to determine what these additional costs will be prior to bidding/buying.

  • For custom clearance procedure, If you need help, please let us know

Shipping Notice:

Remote area addition fee(FedEx & DHL

A Remote Area is defined as a post code or in the absence of post code, a suburb /town name that is difficult to serve. A delivery to one of the following post codes and towns would attract a Remote Area surcharge.

For Import Express shipments, a pickup from one of the same post codes and towns would attract a Remote Area surcharge. Please refer to your service guide for the surcharge amount in local currency

WARRANTY/QUALITY

  • CE certified.

  • 100% QC before shipment.

  • Standard 1 year product warranty

  • Warranty will cover only items that are deemed to fail under normal usage. Accidental damage due to environmental causes or incorrect usage and installation will not be covered in warranty (but still serviceable

  • we will provide free pcb board during the warranty,but buyer need to pay for the shipment fee.

  • Contact us directly for warranty issues

  • Buyer is responsible for warranty return shipping.

Additional information

Ships From

China, GERMANY
